德國MAROS角座閥
MAROS角座閥 VAL.FLUXA規格信息：
•Sizes： 1/2" - 2" (PN16)
•Pipe threads： F/F gas ISO228
•Normally closed (NC)：cod. 51….
•Normally open (NO)：cod. 52….
•Double acting (DA)：cod. 53….
•Ambient temperature ：-20°C- +60°C
•Pilot pressure： Min 4.5 bar - Max 8 bar
•Valve body：Fluxa/Fluxa “D” Brass; Fluxa “DC”/Fluxa “C” nickelplated brass
MAROS角座閥 VAL.FLUXA NC 2" COD. 51200
MAROS角座閥 VAL.FLUXA NC 1" COD. 51100
MAROS角座閥 VAL.FLUXA NC 1/2" COD. 51012
| MAROS角座閥 VAL.FLUXA 訂貨號： | ||
| Codice | Filett. [gas] | DN |
| Code | Gas pipe thread | |
| 51012 | 1/2" | 15 |
| 51034 | 3/4" | 20 |
| 51100 | 1" | 25 |
| 51114 | 1”1/4 | 32 |
| 51112 | 1"1/2 | 40 |
| 51200 | 2" | 50 |
| 52012 | 1/2" | 15 |
| 52034 | 3/4" | 20 |
| 52100 | 1" | 25 |
| 52114 | 1"1/4 | 32 |
| 52112 | 1"1/2 | 40 |
| 52200 | 2" | 50 |
| 53012 | 1/2" | 15 |
| 53034 | 3/4" | 20 |
| 53100 | 1" | 25 |
| 53114 | 1"1/4 | 32 |
| 53112 | 1"1/2 | 40 |
| 53200 | 2" |
50 |
